PROSINE 2.0 INVERTER•CHARGER USER’S MANUAL
iv
445-0089-01-01
Adjustable From the Configure Battery Menu
NOTE
Settings below are for Battery Type = Generic Gel.
Battery Size 200Ah
**
Default Battery Temperature Warm
Battery Type Generic Gel
**
Battery Temp. Coefficient –27mV/°C
Bulk Mode Settings:
• Max Voltage
• Max Current (%C)
• Exit Voltage
• Exit Timeout
• 14.2V
• 25%
• 13.8V
•3min
Absorption Mode Settings:
• Max Voltage
• Max Current (%C)
•Max Abs Time
• Exit Current (%C)
• Exit Timeout
• 14.2V
• 25%
• 8hr
•1%
•3min
Overcharge Mode Settings:
• Max Voltage
• Max Current (%C)
• Overchg Timeout
• 14.2V
• 20%
•0
Float Mode Settings:
• Max Voltage
• Max Current (%C)
• Max Float Time
• Exit Voltage
• Exit Timeout
• 13.8V
• 200%
• 21days
• 12.5V
• 15min
Equalize Mode Settings:
• Max Voltage
• Max Current (%C)
•Max EQ Time
• Exit Voltage
• Exit Timeout
• 13.8V
• 200%
•0
•0
•0
Constant Mode Settings:
• Voltage Setpoint
• Current Setpoint
• 13.5V
• 100A
Charger Mode Standalone
Charger Type 3-Step
NOTE
The values opposite the gray bar are set when you
select a battery type. If you did not subsequently
change these settings, they do not need to be
recorded.
Table 1 Default Values: Inverter•Charger
Item Default Value Your Settings
