SECTION 3 INSTALLATION
445-0089-01-01
37
The surface where the sensor is to be mounted must be flat and free from
reinforcing ribs or other raised features. As well, this surface must be in
direct internal contact with battery electrolyte, so do not install the sensor
on a side near the top of the battery or on the battery’s top surface.
3. Clean the selected area thoroughly to remove any oil or grease that could
prevent the sensor from adhering to the battery case, and allow the battery
case to dry thoroughly.
4. Peel the protective backing from the self-adhesive strip on the rear of the
sensor.
5. Press the sensor firmly against the clean side of the battery to fix it in
place.
6. Route the sensor cable to the inverter•charger and plug it into the
BATTERY TEMP
jack. Secure the cable along its length.
