Service Parts Disassembly 8-47

Replacement Notes:

Note

Route the solenoid harness through the right side frame when replacing the

upper duplex guide. Also, you must route the guide under the edges of the

exit module assembly (EMA) frame.

Note

Verify that the solenoid lever engages the hole in the Paper Release Guide.
