Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones
994
Step
Action
Description
initiator in the From field.
 A unique numeric identifier is
assigned to the call and is inserted in
the Call-ID field.
 The transaction number within a
single call leg is identified in the CSeq
field.
 The media capability User A is ready
to receive is specified.
 The port on which User B is prepared
to receive the RTP data is specified.
F2
INVITE—Proxy Server to User B
The proxy server maps the SIP URI in the To
field to User B. The proxy server sends the
INVITE message to User B.
F3
100 Trying—User B to Proxy
Server
User B sends a SIP 100 Trying response to
the proxy server. The 100 Trying response
indicates that the INVITE request has been
received by User B.
F4
100 Trying—Proxy Server to User
A
The proxy server forwards the SIP 100
Trying to User A to indicate that the INVITE
request has been received by User B.
F5
180 Ringing—User B to Proxy
Server
User B sends a SIP 180 Ringing response to
the proxy server. The 180 Ringing response
indicates that the User B is being alerted.
F6
180 Ringing—Proxy Server to
User A
The proxy server forwards the 180 Ringing
response to User A. User A hears the
ring-back tone indicating that User B is
being alerted.
F7
200 OK— User B to Proxy Server
User B sends a SIP 200 OK response to the
proxy server. The 200 OK response notifies
User A that the connection has been made.
F8
200OK—Proxy Server to User A
The proxy server forwards the 200 OK
message to User A. The 200 OK response
notifies User A that the connection has
been made.
F9
ACK—User A to Proxy Server
User A sends a SIP ACK to the proxy server.
The ACK confirms that User A has received
the 200 OK response. The call session is
