Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones
1006
ACK—User A to Proxy Server
User A sends an ACK message to the proxy
server. The ACK confirms that User A has
received the 200 OK response. The call
session is now temporarily inactive. No RTP
packets are being sent.
ACK—Proxy Server to User B
The proxy server sends the ACK message to
User B. The ACK confirms that the proxy
server has received the 200 OK response.
200 OK—User A to Proxy Server
User A sends a 200 OK response to the
proxy server. The 200 OK response notifies
that the connection has been made.
200 OK—Proxy Server User C
The proxy server forwards the 200 OK
message to User C.
ACK—User C to Proxy Server
User C sends a SIP ACK to the proxy server.
The ACK confirms that User C has received
the 200 OK response. The call session is
now active.
ACK—Proxy Server to User A
The proxy server forwards the SIP ACK to
User A to confirm that User C has received
the 200 OK response.
The following figure illustrates a successful call between Yealink SIP IP phones in which two
parties are in a call and then one of the parties transfers the call to a third party without
consultation. This is called a blind transfer. In this call flow scenario, the end users are User A,
User B, and User C. They are all using Yealink SIP IP phones, which are connected via an IP
network.
