Yealink SIP-T2 Series User Manual

Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones
996
The call cannot be set up successfully.
User A Proxy Server User B
F1. INVITE B
F2. INVITE B
F3. 100 Trying
F4. 100 Trying
F5. 486 Busy Here
F6. 486 Busy Here
F7. ACK
F8. ACK
Step
Action
Description
F1
INVITE—User A to Proxy Server
User A sends the INVITE message to a
proxy server. The INVITE request is an
invitation to User B to participate in a call
session.
In the INVITE request:
 The IP address of User B is inserted in
the Request-URI field.
 User A is identified as the call session
initiator in the From field.
 A unique numeric identifier is
assigned to the call and is inserted in
the Call-ID field.
 The transaction number within a
single call leg is identified in the CSeq
field.
 The media capability User A is ready
to receive is specified.
 The port on which User B is prepared
to receive the RTP data is specified.
F2
INVITE—Proxy Server to User B
The proxy server maps the SIP URI in the To
field to User B. Proxy server forwards the
INVITE message to User B.
F3
100 Trying—User B to Proxy
Server
User B sends a SIP 100 Trying response to
the proxy server. The 100 Trying response
