Yealink SIP-T2 Series

Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones
478
programablekey.X.label/
expansion_module.X.key.Y.label
Web User Interface
Assign a recall key.
Navigate to:
http://<phoneIPAddress>/servlet?p
=dsskey&q=load&model=0
Phone User Interface
Assign a recall key.
ReCall Key
For more information on how to configure the DSS Key, refer to Appendix D: Configuring DSS
Key on page 948.
Details of Configuration Parameters:
Parameters
Permitted Values
Default
linekey.X.type/
programablekey.X.type/
expansion_module.X.key.Y.type
7
Refer to the
following content
Description:
Configures a DSS key as a recall key on the IP phone.
The digit 7 stands for the key type ReCall.
For line keys:
X ranges from 1 to 29 (for SIP-T48G/S)
X ranges from 1 to 27 (for SIP-T46G/T46S/T29G)
X ranges from 1 to 27 (for SIP-T46G/T46S/T29G)
X ranges from 1 to 15 (for SIP-T42G/T42S/T41P/T41S)
X ranges from 1 to 21 (for SIP-T27P/T27G)
X ranges from 1 to 3 (for SIP-T40P/T40G/T23P/T23G)
X ranges from 1 to 2 (for SIP-T21(P) E2)
For programable keys:
X=1-10, 12-14 (for SIP-T48G/T48S/T46G/T46S)
X=1-10, 13 (for SIP-T42G/T42S/T41P/T41S/T40P/T40G)
X=1-14 (for SIP-T29G/T27P/T27G)
X=1-10, 14 (for SIP-T23P/T23G/T21(P) E2)
X=1-9, 13, 14 (for SIP-T19(P) E2)
For ext keys:
For SIP-T48G/T48S/T46G/T46S:
X ranges from 1 to 6, Y ranges from 1 to 40.
