Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones
662
Parameters
Permitted Values
Default
For SIP-T29G/T27P/T27G:
X ranges from 1 to 6, Y ranges from 1 to 20, 22 to 40 (Ext key 21 cannot be configured).
Example:
linekey.2.value = http://10.3.5.97:8080/URLRecord/record.xml
Note: It is not applicable to SIP-T19(P) E2 IP phones.
Web User Interface:
Dsskey->Line Key->Value
Phone User Interface:
Menu->Features->DSS Keys->Line Key X->Value
linekey.X.label/
expansion_module.X.key.Y.label
String within 99
characters
Blank
Description:
(Optional.) Configures the label displayed on the LCD screen for each DSS key.
For line keys:
X ranges from 1 to 29 (for SIP-T48G/S)
X ranges from 1 to 27 (for SIP-T46G/T46S/T29G)
X ranges from 1 to 15 (for SIP-T42G/T42S/T41P/T41S)
X ranges from 1 to 21 (for SIP-T27P/T27G)
X ranges from 1 to 3 (for SIP-T40P/T40G/T23P/T23G)
X ranges from 1 to 2 (for SIP-T21(P) E2)
For ext keys:
For SIP-T48G/T48S/T46G/T46S:
X ranges from 1 to 6, Y ranges from 1 to 40.
For SIP-T29G/T27P/T27G:
X ranges from 1 to 6, Y ranges from 1 to 20, 22 to 40 (Ext key 21 cannot be configured).
Note: It is not applicable to SIP-T19(P) E2 IP phones.
Web User Interface:
Dsskey->Line Key->Label
Phone User Interface:
Menu->Features->DSS Keys->Line Key X->Label
To configure a record key via web user interface:
1. Click on Dsskey->Line Key.
2. In the desired DSS key field, select Record from the pull-down list of Type.
