6-14
IM WT18
O
1E-02EN
Saving Display Configuration Files (Save Custom Items)
Press the Save Custom Items soft key to display the following menu.
Set the save destination. ► section 17.2
Saves the display configuration
Note that if a file with the same name exists in the destination folder, it will be overwritten
without warning.
File names are not case-sensitive.
Set auto naming. ► section 17.2
Set the file name. ► section 17.2
Loading Display Configuration and Background Files at the Same
Time (Load Items & Bmp)
Follow the procedure on page 6-12 to display the Custom Items menu, and then press the Load Items
& Bmp soft key to display the following screen.
Loads the file
Select the file that you want to load.
Select a custom display file.
Display configuration files: .txt files
Background files: .bmp files
To load both a display configuration file and
background file at the same time, load the display
configuration file.
However, an error will occur if a background file
that has the same name as the display
configuration file is not present in the save
destination folder of the display configuration file.
For the operating procedure, see section 17.6.
6.7 Setting the Custom Display
