13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 4-9
Maintenance Section 4
Exterior: The exterior surfaces of the printer may be cleaned as required by using a lint-
free cloth. Do not use solvents or harsh cleaning agents. If the unit is excessively dirty, a
mild detergent solution or desktop cleaner may be used sparingly.
Interior: As required, use a soft-bristle brush or vacuum cleaner to remove any dirt or lint
accumulated in the interior of the printer. It is a good practice to inspect these areas after
every four rolls of media.
Cleaning supplies: A preventive maintenance kit (Zebra part number 01429) containing
six cleaning swabs soaked in solvent (alcohol and distilled water) is available from
Zebra Technologies.
Figure 4-1. Cleaning a Typical Printhead
Caution:
The use of certain lubricants such as penetrating oil and silicone oil will damage
the printers spindles and inhibit proper operation. Do not lubricate any parts in
this printer unless called for in the installation and adjustment procedure.
Ribbon
Sensor
Black
Mark
Sensor
Peel-Off/Tear-Off
Bar
Platen
Roller
Label-Available
Sensors
Printhead
Printhead
Lever
