Page 1-6 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 1 System Description
Media Considerations
Media Specifications
In inches (mm)
Minimum label length Tear-off 0.7 (18)
Peel-off 0.5 (13)
Cutter 1.5 (38)
Rewind 0.25 (6)
Total media width
(includes liner)
Minimum 0.79 (20)
Maximum 4.5 (114)
Total thickness
(includes liner)
Minimum 0.003 (0.076)
Maximum 0.012 (0.305)
Cutter maximum full-width
media thickness
0.009 (0.23)
Roll media core diameter 3 (76)
Maximum roll diameter 8 (203)
Interlabel gap Minimum 0.079 (2)
Preferred 0.118 (3)
Maximum 0.157 (4)
Maximum internal fanfold media pack size
(label + liner) L × W × H
8.0 × 3.54 × 4.5 (203 × 140 × 114)
Ticket/tag sensing notch L × W 0.12 × 0.25 (3 × 6)
Ticket/tag sensing hole diameter 0.125 (3)
Effective leading edge
registration accuracy*
Vertical ±0.060 (±1.5)
Horizontal ±0.060 (±1.5)
Additional
specs for
black mark
sensing
Mark length
(measuring
parallel to label/tag
edge)
Minimum 0.12 (3)
Maximum 0.43 (11)
Mark width
(measuring
perpendicular to
label/tag edge)
Minimum 0.43 (11)
Maximum Full media width
Mark location Marks must be located within 0.040 (1)
of inside media edge.
Mark density > 1.0 ODU (Optical Density Unit)
Maximum density of liner on which
black mark is printed
0.5 ODU
* Media registration and minimum label length are affected by media type and width,
ribbon type, print speed, and printer mode of operation. Performance improves as these
factors are optimized. Zebra recommends always qualifying any application with thorough
testing.
