13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 2-35
Operations Overview Section 2
Set Communication Parameters
Communication parameters must be set correctly for the printer to receive data from the
host. These parameters ensure that the printer and host are speaking the same language.
All communications parameters are password-protected.
Parallel Communications
Select the communications port that matches the one used by the host computer.
Press the right or left oval key to display other selections.
Serial Communications
Select the communications port that matches the one used by the host computer.
Press the right or left oval key to display other choices.
Press NEXT/SAVE to display BAUD.
Baud Rate
The baud rate of the printer must match the baud rate of the host for communications to
take place. Select the baud rate that matches the one used by the host.
Press the right oval key to increase the value, or press the left oval key to decrease the
value.
Press NEXT/SAVE to display DATA BITS.
Default: Parallel
Selections: Parallel, Twinax/Coax
Default: RS232
Selections: RS232, RS422/485, RS485 Multidrop
Default: 9600
Selections:
110, 300, 600, 1200, 2400, 4800, 9600, 14400, 19200, 28800, 38400,
57600, 115200
PARALLEL COMM.
PARALLEL
SERIAL COMM.
Rs232
BAUD
- 9600 +
