Page 4-60 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 4 Maintenance
7. Refer to RRP No. 3 on page 4-17. Reinstall the AC/DC power supply.
8. Reconnect all cables to the power supply and verify proper placement and
orientation.
9. Refer to RRP No. 2 on page 4-16. Reinstall the electronics cover.
10. Reconnect the AC power cord.
11. Turn the printer On (l). Enter Configuration Mode and set the printer to
Cutter Mode. Save as PERMANENT and turn the printer Off (O).
12. Load media and ribbon, press and hold PAUSE while turning the printer On (l), and
run labels through the printer. Test the cutter for proper operation.
13. Reconnect data cables and turn the printer On (l).
Retiming the Upper Drive Arm
If the media hits either cutter blade or if the cutter does not cut through the label material
completely, the upper drive arm alignment must be checked.
1. Refer to RRP No. 1 on page 4-14. Turn the printer Off (O), remove the AC power
cord and data cables.
2. Refer to RRP No. 2 on page 4-16 and remove the electronics cover.
3. Refer to RRP No. 3 on page 4-17 and remove the power supply.
4. Hold the upper drive arm in a stationary position and adjust the rotary cutter blade to
a gap of approximately 0.100 in. (2.5 mm) between the cutting edge on the left end
and the cutting edge of the rear cutter blade, as shown in Figure 4-36.
Note • The upper drive arm is part of the cutter mechanical assembly and has
been aligned at the factory. If the position is altered, the following procedure
may be used to realign the upper drive arm. The printer must be programmed
to operate in Cutter Mode prior to performing the following procedure.
Caution:
Unless indicated otherwise, turn the printer Off (O) and disconnect the printer
from the power source before performing the following maintenance.
Caution:
This installation must be performed by a qualified service technician.
