Page 4-18 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 4 Maintenance
5. Refer to Figure 4-8. Unplug all connectors from the AC/DC power supply.
6. Remove the mounting screw and two nuts securing it.
7. Remove the power supply assembly.
Install the Power Supply
1. Refer to Figure 4-8. Ensure the heat-conduction pad is in position. Move the cables
out of the way while installing the AC/DC power supply assembly.
2. Reinstall the mounting screw and nuts securing the power supply assembly.
3. Connect all the cable connectors on the power supply board as shown in Figure 4-8.
4. Reinstall the insulation shield, ensuring the top is dressed properly. Secure the
insulation shield to the standoffs with two screws.
5. Dress the wire harnesses across the top of the insulation shield, and secure them
with the cable tie.
6. Reinstall the electronics cover.
7. Reconnect the AC power cord and all data cables and supply power.
8. Press and hold PAUSE while turning the printer On (I). Observe the printer
Power-On Self Test and examine the test labels for proper print quality.
Note • The black heat-conduction pad must not be discarded.
