13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 4-45
Maintenance Section 4
8. Slide the platen roller as far to the left as possible to free the right end. Remove the
platen roller.
Install the Upper Platen Roller
1. Orient the replacement platen roller so the end of the roller with the flats for the
pulley is on the left side when facing the front of the printer.
2. Insert the left end of the shaft into the hole in the main frame. Then, place the right
end of the roller through the side plate.
3. Note the correct orientation of the new bearings. Install the new bearing and the
washer on the right of the platen roller. Secure the bearing and washer with the
C-clip.
4. Install a new bearing, the spacer, and the pulley on the end of the platen roller with
the two flats.
5. Ensure that both set screws in the platen roller pulley align with the flats on the
platen roller shaft.
6. Adjust the platen roller pulley on the left side of the platen roller shaft. Leave a gap
of approximately 0.020 in. (0.5 mm) between the spacer and the platen roller pulley.
7. Tighten the two set screws to secure the pulley to the shaft.
8. Reinstall and adjust the main drive belt.
9. Reinstall the electronics cover.
10. Reinstall the media and ribbon. Close the printhead.
11. Close the media cover.
12. Reconnect data cables and power cord.
13. Turn the printer On (l).
Caution:
Never reuse the old bearings. Use only the new bearings that were provided
with the replacement platen roller.
