RRP No. 6: Remove and Install the Main Drive Belt
Remove the Main Drive Belt
1. Refer to RRP No. 1 on page 4-14. Place the power switch in the Off (O) position,
and disconnect the AC power cord. Disconnect all data cables.
2. Open the media cover.
3. Open the printhead and remove all media and ribbon. Close the printhead.
4. Refer to RRP No. 2 on page 4-16 and remove the electronics cover.
5. Refer to Figure 4-13. Rotate the ribbon take-up pulley until the three holes in the
pulley align with the three mounting screws that secure the ribbon take-up spindle
assembly.
6. Through the holes in the ribbon take-up pulley, loosen the three spindle assembly
mounting screws.
7. Slide the ribbon take-up spindle assembly to the right to relieve the tension on the
main drive belt.
8. Refer to Figure 4-13. Remove the main drive belt by sliding it off the ribbon take-up
pulley.
Install Main Drive Belt
1. Install the replacement main drive belt around the outer gear of the stepper motor
pulley, the platen pulley, and the ribbon take-up pulley.
2. Hook a 2200-gram spring scale to the belt as shown in Figure 4-13 and carefully
slide the ribbon take-up spindle assembly to the left to increase belt tension.
3. When a scale reading of 2000 grams ±250 grams (4.5 lbs. ±0.5 lbs.) creates a
deflection of 1/4 in. (6 mm), tighten the three mounting screws to a torque of
20 inch-pounds (2.3 N
•m).
4. Reinstall the electronics cover.
5. Reinstall media and ribbon then close the printhead.
6. Close media cover.
7. Reconnect data cables and AC power cord.
8. Turn the printer On (l).
Caution:
Unless indicated otherwise, turn the printer Off (O) and disconnect the printer
from the power source before performing the following maintenance.
Caution:
This installation must be performed by a qualified service technician.
