Page 4-24 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 4 Maintenance
Figure 4-13. Main Drive Belt
2200
2000
1800
1600
1400
INCHES
1
2
3
Spring
Scal
e
Access to
Mounting
Screws
