Page 4-112 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 4 Maintenance
Optional Cutter Kit
Adding the Cutter Option (Zebra part number 41353) to this printer requires the
installation of several parts and assemblies and should be performed only by a qualified
service technician.
The service technician must follow all of the step-by-step procedures provided in these
instructions.
* See the parts breakdown in “Maintenance and Assembly Drawings” on page 5-29.
Table 4-6. Cutter Parts List
3
Item Qty Part Number Description
14HW30391-003 Screw 4-40 (only available in quantities of 25)
2149730M Cutter Option Circuit Board
3149604-010 Cutter Power Cable
4149600-012 Cutter Data Cable
5131313 Sensor Clamp
6101822 Nut
7146618M Cutter Optical Sensor Assembly
81 N/A Cutter Module Assembly
94HW30392-004 Screw 6-32 (only available in quantities of 50)
10 1 46224 Grommet
11 1 30374M Cutter Motor Assembly
12 2 30394-005 Screws (Motor Mounting)
13 1 47385 Cutter Catch Tray Kit
14 1 30405-006 Screw, 1/4-20 × 0.38
15 1 HW02133 E-Ring (only available in quantities of 50)
16 1 N/A* Drive Link Assembly
17 1 30449 Allen Wrench, 5/64 in.
18 1 44632 Ferrite Core
N/A = Not available as a separate part (listed for identification purposes only).
Bold=Part available for purchase
Light italic = Part not available for purchase, listed and shown for reference only
