Page 4-68 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 4 Maintenance
6. With the recessed side facing away from the main frame, slide the replacement
pulley onto the ribbon take-up shaft.
7. Reinstall the E-ring to secure the pulley.
8. Install the main drive belt.
9. Refer to RRP No. 5 on page 4-23 and adjust the tension on the main drive belt.
10. Reinstall the electronics cover.
11. Reconnect the data cables and the AC power cord.
12. Turn the printer On (l).
Replace the Media Take-Up Pulley
1. Refer to RRP No. 1 on page 4-14. Turn the printer Off (O), remove the AC power
cord and data cables.
2. Refer to RRP No. 2 on page 4-16 and remove the electronics cover.
3. Refer to RRP No. 3 on page 4-17 and remove the power supply.
4. Refer to RRP No. 6 on page 4-25 and remove the main drive belt.
5. Refer to RRP No. 8 on page 4-28 and remove the rewind drive belt.
6. Refer to Figure 4-42. Remove the E-ring securing the pulley.
Note • Do not remove the spacer, flat washer, and wave washer.
Caution:
Unless indicated otherwise, turn the printer Off (O) and disconnect the printer
from the power source before performing the following maintenance.
Caution:
This installation must be performed by a qualified service technician.
Caution:
Wear protective eyewear when removing E-rings, C-clips, snap rings, and
springs. All of these are under tension and could fly off while being removed.
