13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 2-45
Operations Overview Section 2
Set Applicator Port
Determines the action of the verifier port.
Off: The applicator port is off.
Mode 1: Asserts the ~END_PRINT signal low while the printer is moving the label
forward.
Mode 2: Asserts the ~END_PRINT signal high while the printer is moving the label
forward.
Mode 3: Asserts the ~END_PRINT signal low for 20 milliseconds when a label has been
completed and positioned. Not asserted during continuous printing modes.
Mode 4: Asserts the ~END_PRINT signal high for 20 milliseconds when a label has
been completed and positioned. Not asserted during continuous printing modes.
Press NEXT/SAVE to display START PRINT SIG.
Set Start Print Signal
This parameter determines how the printer reacts to the Start Print Signal input on pin 3 of
the applicator interface connector at the rear of the printer.
Press the right or left black oval key to display other choices.
• In Pulse Mode, labels print when the signal transitions from HIGH to LOW.
• In Level Mode, labels print as long as the signal is asserted LOW.
Press NEXT/SAVE to display RESYNCH MODE.
Note • Set as suggested by the applicator manufacturer.
Default: Off
Range: Off, mode 1, mode 2, mode 3, mode 4
APPLICATOR PORT
OFF
Default: Pulse Mode
Range: Pulse Mode, Level Mode
Caution:
Start Print Signal is set by the applicator manufacturer and should not be
changed unless the factory defaults have been reloaded. The printer must be
returned to its designated setting to work properly.
START PRINT SIG
PULSE MODE
To Next Page
