Page 4-64 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 4 Maintenance
14. Turn the printer On (l). Enter Configuration Mode and set the printer to Cutter
Mode. Save as PERMANENT
and turn the printer Off (O).
15. Load media and ribbon, press and hold PAUSE while turning the printer On (l), and
run labels through the printer.
16. Reconnect the data cables.
Replace the Transmissive Media Sensor
Remove the Sensor
1. Refer to RRP No. 1 on page 4-14. Turn the printer Off (O), remove the AC power
cord and data cables.
2. Refer to RRP No. 2 on page 4-16 and remove the electronics cover.
3. Open the media cover.
4. Open the printhead and remove all media and ribbon. Close the printhead.
5. Refer to Figure 4-38. Remove thumbscrews securing the upper media sensor
bracket assembly.
Note • If the media hits either cutter blade or if the cutter does not cut through
the label material completely, perform the procedures in Retiming the Upper
Drive Arm on page 4-60, before completing the installation.
Caution:
Unless indicated otherwise, turn the printer Off (O) and disconnect the printer
from the power source before performing the following maintenance.
Caution:
This installation must be performed by a qualified service technician.
