Zebra 110XiIII Plus Series User Manual

13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 4-111
Maintenance Section 4
Figure 4-73. Applicator Installation
J1
J5
J4
Mounting
Screws
Connect to one
of the open serial
connectors on
the main logic board.
Connect to one
of the open power
connectors on the
DC power supply board.
J4 — Applicator
Connector
Applicator
Interface Board
J5 — Power
Connector
