13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 4-89
Maintenance Section 4
Table 4-2. Parts List
3
Item Qty Part Number Description
1 3 HW30393-006 Screw, 8-32 (only available in quantities of 25)
2 6 HW40193 Flat Washer,
3 2 48688 Flange Bearing (Part of Platen Roller Kit)
4 1 41011M Platen Roller Kit
4 1 41016M Platen Roller Kit (600 dpi)
5 1 41155M Rewind Spindle Assembly Kit
6 1 HW47062-1 J-Hook (only available in quantities of 5)
7 1 40019 Platen Support Bracket
8 3 HW30392-004 Screw, 6-32 (only available in quantities of 50)
9 1 02252 E-Ring
10 41383M Rewind Plate Kit
11 1 30334-7 Bearing Housing Assembly Kit
12 1 31336M RTU/MTU Pulley Assembly Kit
12 1 33094-6M RTU/MTU Pulley Assembly Kit (600 dpi)
13 1 HW30118 E-Ring (only available in quantities of 25)
14 1 45189-2 Rewind Drive Belt
14 1 45189-13 Rewind Drive Belt (600 dpi)
15 1 HW30114 Washer, Flat (only available in quantities of 25)
16 1 HW30115 Washer, Wave (only available in quantities of 25)
17 1 30914M Rewind Platen Pulley Kit
17 1 47915M Rewind Platen Pulley Kit (600 dpi)
18 1 46609-4M Take-Label Sensors Assembly Kit
19 2 HW07435 Screw, 6-32 (only available in quantities of 100)
20 1 30265 Idler Pulley
21 1 N/A Spacer (Part of Platen Roller Kits)
22 1 30207 Idler Shaft
23 1 N/A Spacer (Part of 31336M)
N/S 1 11301 Allen Wrench, Long 7/64 inch
N/A – Not available as separate service item
N/S – Not shown
Bold = Part available for purchase
Light italic
= Part not available for purchase, listed and shown for reference only
To Next Page
