Page 5-8 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 5 Maintenance and Assembly Drawings
Table 5-3. Print Mechanism Assembly 110XiIIIPlus (View 1)
Item Part Number Description Qty
1 HW30392-004 Screw, 6–32 × 0.25 (Available in quantities of 50) 13
2 REF Tri Mount Shoulder 1
3 46352M Flag Maintenance Kit 1
4 01130 Nut, 6–32 Hex Washer Head 1
5 22613M Head Open Switch Assembly Maintenance Kit 1
6 30266 Head Lift Spring Stop 1
7 40462 Media Take-up Sensor Cover 2
8 HW06268 Lock Washer #6 (Available in quantities of 25) 3
9 HW30392-006 Screw, 6–32 × 0.37 (Available in quantities of 25) 2
10 HW48023 Bearing, 0.313 × 0.190 × 0.375 (Available in quantities of 25) 1
11 47009-11 Roller, 0.37 0.312 × 5.437 1
12 30007-12 Roller, Shaft 0.185 × 5.5 1
13 HW44001 Self-Tap Screw, M3.5 × 11mm with 5mm Head (Available in quantities of 25) 11
14
40355M Platen Pulley Maintenance Kit 1
33079-6M Platen Pulley Maintenance Kit (600 dpi) 1
15 22004-2 Spacer 1
16 38226M Reflective Media Sensor Maintenance Kit 1
17
30007-12 Roller Shaft 0.185 × 5.500 (600 dpi printers only) 1
18 48011-9 Roller 5.440 (600 dpi printers only) 1
19 HW30256-B Thumb Nut (Available in quantities of 25) 1
20 41305M Media Guide Assembly 1
21 30033 Adjustable Media Guide 1
22 46267 Hole Plug, 0.5 Diameter × 0.125 thick 12
23 46091 Grommet, for a 1.25 × 0.625 cutout 1
24 30023 Cutter Cover Plate 1
25
46224 Rubber Grommet, 0.312 × 0.34 × 0.109 1
26
46199M Stepper Motor and Pulley Maintenance Kit (300 dpi) 1
46198M Stepper Motor and Pulley Maintenance Kit (203 dpi) 1
33084M Pulley Maintenance Kit (600 dpi) 1
27 HW30393-006 Screw, 8–32 × 0.37 (Available in quantities of 25) 4
28 49688 Flanged Ball Bearing, 0.5 × 0.250 × 0.125 2
29
HW30105 Nylon Bearing, 0.312 × 0.251 × 0.078 (Available in quantities of 25) 1
30 HW46105 Nylon Bearing, 0.312 × 0.251 × 0.140 (Available in quantities of 25) 1
31 41028 Peel/Tear-Off Bar 1
32
41011M Platen Roller Maintenance Kit (203/300 dpi) 1
41016M Platen Roller Maintenance Kit (600 dpi) 1
33 02252 Crescent Ring, 0.250 Yel 2
