Page 5-10 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 5 Maintenance and Assembly Drawings
Table 5-3. Print Mechanism Assembly 110XiIIIPlus (View 1) (Continued)
Item Part Number Description Qty
34 HW30247 Washer, 0.420 × 0.260 × 0.0747 1
35
41043 Upper Media Guide (Snap Plate) (203/300 dpi) 1
41015 Upper Media Guide (Snap Plate) 600 dpi 1
36 Q10019 E-Ring, Ext, 0.250 1
37 41022M Pivot Bar Maintenance Kit 1
38
35099M Toggle Assembly Maintenance Kit 2
39 41302M Media Sensor Maintenance Kit (Includes Upper and Lower Sensor) 1
40 HW48411 Thumb Screw (Available in quantities of 10) 2
41 41691M Dancer Arm Assembly Maintenance Kit, w/Springs (200 and 300 dpi only) 1
42 33189 Washer 1
43 HW07229 Wave Washer, 0.49 × 0.33 × 0.0075 (Available in quantities of 50) 1
44 30391-006 Set Screw 1
45
40248 Shaft Wear Plate 1
46
40154 Eccentric Pin 1
47
30956 Flat Washer 0.207 × 0.146 × 0.030 2
48 HW30392-008 Screw, 6-32 × 0.50 (Available in quantities of 25) 1
49 30826 Hole Plug 2
50 30255 Hole Plug 1
Bold=Part available for purchase
Italic=Part not available for purchase, listed and shown for reference only
