Page 5-18 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 5 Maintenance and Assembly Drawings
Table 5-6. Printhead Support Assembly (Continued)
Item Part Number Description Qty
22
33141
Printhead Power Cable (200 and 300 dpi) 1
47640 Printhead Power Cable (600 dpi) 1
23 46665M Ribbon Sensor Maintenance Kit 1
24
41014 Guard Plate (200 and 300 dpi) 1
47014 Guard Plate (600 dpi) 1
25
41062 Head Pivot Bar (200 and 300 dpi) 1
41034 Head Pivot Bar (600 dpi) 1
26 HW40193 Flat Washer 0.406 × 0.172 × 0.048 (only available in quantities of 25) 2
27 HW40194 Curved Washer, 0.344 × 0.172 × 0.006 (only available in quantities of 25) 2
28 HW46481-1 Adjustment Screw M3.5 (only available in quantities of 5) 2
Bold=Part available for purchase
Italic=Part not available for purchase, listed and shown for reference only
