13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 5-23
Maintenance and Assembly Drawings Section 5
Table 5-10. Communication Options (Continued)
Figure 5-10. Communication Options
Item Part Number Description Qty
24
27056 Coupler Cable (Multi-Protocol) (Not Illustrated) RFID kits are available
for Zebra Authorized Service Providers only.
1
25
27059-09 Interface Cable (Multi-Protocol) (Not Illustrated) RFID kits are available
for Zebra Authorized Service Providers only.
1
26
49604-010 Power Supply Cable (Multi-Protocol) (Not Illustrated) RFID kits are
available for Zebra Authorized Service Providers only.
1
27 41110M Printhead Test Option Kit (Not Illustrated) 1
Bold=Part available for purchase
Italic=
Part not available for purchase, listed and shown for reference only
