Page 5-30 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 5 Maintenance and Assembly Drawings
Table 5-13. Cutter Option Assembly (View 1) (Continued)
Item Part Number Description Qty
34 30819 Cutter Support Bracket 1
35 30196-100 Cutter Module 1
36 30320 Carbon Brush, 4.50 × 0.50 1
37 30181 Upper Cutter Guide 1
38 46807 Upper Cutter Bracket 1
39 Q10011
Screw, M4 × 0.7 2
Bold=Part available for purchase
Italic=Part not available for purchase, listed and shown for reference only
