13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 2-15
Operations Overview Section 2
Figure 2-10. Fanfold Media
Closed
Printhead Lever
Open
Media
Guide
Media
Rear Supply
Printhead Lever
Open
Closed
Media
Guide
Media
Bottom Supply
