Page 2-22 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 2 Operations Overview
7. The printer automatically adjusts the base settings as determined by the media and
ribbon sensors according to the specific media and ribbon combination you are
using. When this part of the calibration process is completed, the front panel LCD
shows:
8. Open the printhead and pull the media forward until a label is positioned under the
media sensor.
9. Move the ribbon back to its proper position. To ensure that the ribbon is smooth,
rotate the take-up spindle a couple of turns.
10. Close the printhead.
11. Press the right oval key to continue. The printer performs the second part of the
calibration process and the front panel LCD shows:
The media sensor determines label length and a new value based on the presence of media
and liner. The ribbon sensor determines a new value based on the presence of ribbon.
Once media stops feeding, the calibration process is complete.
12. Press SETUP/EXIT to leave Program Mode. When prompted to SAVE
CHANGES PERMANENT, press NEXT/SAVE to save permanently. The front
panel LCD shows:
RELOAD ALL
CONTINUE
MEDIA AND RIBBON
CALIBRATE
SAVE CHANGES
PERMANENT
