Zebra DS8108 User Manual

Standard Parameter Defaults A - 7
Signature Capture 93 5Dh Disable 10-19
Signature Capture Image File Format
Selection
313 F0h 39h JPEG 10-20
Signature Capture Bits per Pixel
(BPP)
314 F0h 3Ah 8 BPP 10-21
Signature Capture Width 366 F4h F0h 6Eh 400 10-22
Signature Capture Height 367 F4h F0h 6Fh 100 10-22
Signature Capture JPEG Quality 421 F0h A5h 65 10-22
Video View Finder 324 F0h 44h Disable 10-23
Video View Finder Image Size 329 F0h 49h 1700 bytes 10-23
Symbologies
Enable/Disable All Code Types
11-8
1D Symbologies
UPC/EAN/JAN
11-9
UPC-A 1 01h Enable 11-9
UPC-E 2 02h Enable 11-9
UPC-E1 12 0Ch Disable 11-10
EAN-8/JAN 8 4 04h Enable 11-10
EAN-13/JAN 13 3 03h Enable 11-11
Bookland EAN 83 53h Disable 11-11
Bookland ISBN Format 576 F1h 40h ISBN-10 11-12
ISSN EAN 617 F1h 69h Disable 11-13
Decode UPC/EAN/JAN
Supplementals
(2 and 5 digits)
16 10h Ignore 11-14
User-Programmable Supplementals
Supplemental 1:
Supplemental 2:
579
580
F1h 43h
F1h 44h
000
11-17
UPC/EAN/JAN Supplemental
Redundancy
80 50h 10 11-17
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
1
SSI
Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
