A - 6 DS8108 Digital Scanner Product Reference Guide
Scan Data Transmission Format 235 EBh Data As Is 9-34
FN1 Substitution Values 103, 109 67h, 6Dh 7013 <CR><LF> 9-36
Transmit “No Read” Message 94 5E Disable 9-37
Unsolicited Heartbeat Interval 1118 F8h 04h 5Eh Disable 9-38
Image Capture Preferences
Operational Modes N/A N/A N/A 10-4
Image Capture Illumination 361 F0h 69h Enable 10-5
Image Capture Autoexposure 360 F0h 68h Enable 10-5
Fixed Exposure 567 F4h F1h 37h 100 10-6
Fixed Gain 568 F1h 38h 50 10-6
Gain / Exposure Priority for Snapshot
Mode
562 F1h 32h Autodetect 10-7
Snapshot Mode Timeout 323 F0h 43h 0 (30 seconds) 10-8
Snapshot Aiming Pattern 300 F0h 2Ch Enable 10-9
Silence Operational Mode Changes 1293 F8h 05h 0Dh Disable (do not silence) 10-9
Image Cropping 301 F0h 2Dh Disable 10-10
Crop to Pixel Addresses 315
316
317
318
F4h F0h 3Bh
F4h F0h 3Ch
F4h F0h 3Dh
F4h F0h 3Eh
0 top
0 left
959 bottom
1279 right
10-10
Image Size (Number of Pixels) 302 F0h 2Eh Full 10-12
Image Brightness (Target White) 390 F0h 86h 180 10-13
JPEG Image Options 299 F0h 2Bh Quality 10-13
JPEG Quality Value 305 F0h 31h 65 10-14
JPEG Size Value 561 F1h 31h 160 kB 10-14
Image Enhancement 564 F1h 34h Low (1) 10-15
Image File Format Selection 304 F0h 30h JPEG 10-16
Image Rotation 665 F1h 99h 0 10-17
Bits per Pixel (BPP) 303 F0h 2Fh 8 BPP 10-18
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
1
SSI
Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
