Zebra DS8108 User Manual

Standard Parameter Defaults A - 5
Presentation (Hands-free) Decode
Aiming Pattern
590 F1h 4Eh Enable Presentation
(Hands-free) Decode Aiming
Pattern on PDF
9-21
Picklist Mode 402 F0h 92h Disable Picklist Mode Always 9-22
Continuous Bar Code Read 649 F1h 89h Disable 9-23
Unique Bar Code Reporting 723 F1h D3h Enable 9-23
Decode Session Timeout 136 88h 9.9 Seconds 9-24
Hands-free Decode Session Timeout 400 F0h 90h 15 9-24
Timeout Between Decodes, Same
Symbol
137 89h 0.5 Seconds 9-25
Timeout Between Decodes, Different
Symbols
144 90h 0.1 Seconds 9-25
Triggered Timeout, Same Symbol 724 F1h D4h Disable 9-26
Mobile Phone/Display Mode 716 F1h CCh Normal 9-27
PDF Prioritization 719 F1h CFh Disable 9-28
PDF Prioritization Timeout 720 F1h D0h 200 ms 9-28
Presentation (Hands-free) Mode Field
of View
609 F1h 61h Full 9-29
Decoding Illumination 298 F0h 2Ah Enable 9-29
Illumination Brightness 669 F1h 9Dh High 9-30
Motion Tolerance (Hand-held Trigger
Mode Only)
858 F2h 5Ah Less 9-31
Miscellaneous Options
Enter Key N/A N/A N/A 9-31
Tab Key N/A N/A N/A 9-31
Transmit Code ID Character 45 2Dh None 9-32
Prefix Value 99, 105 63h, 69h 7013 <CR><LF> 9-33
Suffix 1 Value
Suffix 2 Value
98, 104
100, 106
62h, 68h
64h, 6Ah
7013 <CR><LF> 9-33
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
1
SSI
Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS8108 Specifications

General

Cables included	USB
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	LED
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	5 V
Power consumption	450 mA
Power source type	-
PC connection	RS-232/USB
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP42
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	154 g
