Action 1. To show or hide the Presets, click on the presets tab (1).
9.5.3 Angiography Analysis Presets
1
2
3
4
5
6
7
8
9
10
Figure36: Angiogrphy Analysis Presets and Boundaries
Pos Name Inner Boundary Outer Boundary Example
1 Retina
Depth
Encoded
Combination of the Superficial, Deep, and
Avascular layers with the coding:
• SRL = Red
• DRL = Green
• Avascular = Blue
