15 Specifications
15.1 Imaging Parameters
15.1.1 OCT and OCT Angiography Imaging
Methodology Swept Source OCT
Optical Source Swept Source Tunable Laser
Center Wavelength Centered between 1040 nm-1060 nm;
Sweep range: 980 nm – 1120 nm
Scan Angle 10° minimum
Scan Speed 100,000 A-Scans/sec
Operating Beam Power
(nominal)
4.5 mW at cornea
A-Scan Depth 3.0 mm (in tissue), 1536 points
Axial Resolution (optical) 6.3 µm (in tissue)
Axial Resolution (digital) 1.95 µm (in tissue)
Transverse Resolution* 20 µm
Field of View 56°
Minimum Pupil Diameter 2.5 mm
*Transverse (Lateral) resolution is calculated from beam size at the pupil.
