Zeiss PLEX Elite 9000 - Acquisition Device

3 System Overview Instructions for Use
2660021169042 Rev. A 2018-033.1 Hardware Overview
38 / 246 2660021169042 Rev. A 2018-03
3.1.1 Acquisition Device
1
2
3
4
5
Figure3: PLEX® Elite 9000 Acquisition Device
1 Port for External Fixation Arm 2 Head Rest
3 Imaging Aperture 4 Dual Chin Rest with
Automatic Right/Left Sensors
5 Motorized Patient Alignment
Unit
3.1.2 PC
The PC provides the data and image processing for the PLEX® Elite
9000. The instrument is powered on and off through the power
switch on the front of the PC tower.
1
Figure4: PC
1 On/Off Button
