Zeiss PLEX Elite 9000 - Monitor; Network-Attached Storage (NAS)

Instructions for Use 3 System Overview
2660021169042 Rev. A 2018-03 3.1 Hardware Overview
2660021169042 Rev. A 2018-03 39 / 246
3.1.3 Monitor
1
2
Figure5: Monitor
1 Function Buttons 2 On/Off Button
NOTE!It is not necessary
to turn off the monitor.
3.1.4 Network-Attached Storage (NAS)
1
2
3
Figure6: Network Attached Storage Device
1 Status Indicators 2 USB
3 On/Off Button
NOTE!It is not necessary to turn the NAS off.
