Zeiss PLEX Elite 9000 - 3 System Overview

Instructions for Use 3 System Overview
2660021169042 Rev. A 2018-03 3.1 Hardware Overview
2660021169042 Rev. A 2018-03 37 / 246
3 System Overview
3.1 Hardware Overview
The PLEX® Elite 9000 will be unpacked and installed for you
(components shown below).
1
2
3
4
5 6
8
7
9
10
1 PLEX® Elite 9000 Acquisition
Device
2 PC (Workstation)
3 Computer Shelf 4 Network Switch
5 Network-Attached Storage
(NAS)
6 NAS/Switch Shelf
7 Monitor 8 Pivoting Peripherals Tray
9 Mouse 10 Keyboard
