18. Click Capture (19).
ð The Check Quality screen opens.
19. Check Scan Quality [}97].
8.5.3 Acquire Montage Angio Data
When you acquire a montage, PLEX® Elite 9000 captures a set
series of individual images-- each in a different area-- and stitches
them into a composite image. The composite image provides a
much wider view than a single scan.
• Montage Angio (12mmx12mm) (5-scan composite)
• Montage Angio (15mmx9mm) (2-scan composite)
12mm x 12mm scan order 15mm x 9mm scan order
• Center (C)
• Superior Nasal (SN)
• Superior Temporal (ST)
• Inferior Temporal (IT)
• Inferior Nasal (IN)
• Superior (S)
• Inferior (I)
A montage series takes each of component scans first, then quality
checks all component scans together. You can decide to re-take
any of the component images from the quality check screen before
saving the montage.
You do not need to complete all component scans in the montage
series. You can click Done to save the images that were captured
and skip the remaining component scans of the series.
