Zeiss PLEX Elite 9000 - 4.3.4 Installing Review Station Software

4 Installation Instructions for Use
2660021169042 Rev. A 2018-034.3 Install Review Station Software
50 / 246 2660021169042 Rev. A 2018-03
RAM 16 GB 32 GB
HDD 500 GB 1 TB
Graphics
Capability
1920 x 1080
Table4: System Requirements for stand-alone Review Stations
4.3.3 Review Station Performance
Ethernet Rating 100
Base-T
1 GbE 10
GbE
Speed (MB/sec) 12 120 1200
Network Efficiency 0.5 0.5 0.5
Scan Type Approx. Scan Size Time to Dispay (sec)
12x12 mm HD 1600 ~300 55 31
12x12 mm fast 400 400 14 8
3x3 mm OCT Angiog-
raphy
140 140 5 3
6x6/9x9/12x12 mm
OCT Angiography
270 270 13 7
Table5: Review Station Performance
NOTE
All times are calculated based on an estimated network
performance of 50% of theoretical.
u Actual performance for a typical clinical setting may differ and
will depend on the actual network configruation.
4.3.4 Installing Review Station Software
NOTE
If an error message appears
installation does not occur.
u Press the Print Screen button on your keyboard and save the
error message to inform ZEISS Customer Support: 800–341–
6968. Outside the U.S., contact your local Zeiss distributor.
þ The Review Station fulfills the minimum system requirements
for the Review Software (see: Review Station Requirements
[}49]).
þ The installation media kit is available (see: Software and
Document Media [}49]).
1. Insert the PLEX® Elite 9000 USB flash drive into the computer's
USB port.
