Chapter 15 Firewall
NR/FWA Outdoor Series User’s Guide
188
Figure 132 Security > Firewall > Access Control > Add New ACL Rule
The following table describes the labels in this screen.
Table 74 Security > Firewall > Access Control > Add New ACL Rule
LABEL DESCRIPTION
Filter Name Enter a descriptive name for your filter rule. You can use up to 16 printable characters
except [ " ], [ ` ], [ ' ], [ < ], [ > ], [ ^ ], [ $ ], [ | ], [ & ], or [ ; ]. Spaces are allowed.
Order Assign the order of your rules as rules are applied in turn.
Select Source IP
Address
If you want the source to come from a particular (single) IP, select Specific IP Address. If
not, select from a detected device.
Source IP Address If you selected Specific IP Address in the previous item, enter the source device’s IP
address here. Otherwise this field will be hidden if you select the detected device.
Select Destination
Device
If you want your rule to apply to packets with a particular (single) IP, select Specific IP
Address. If not, select a detected device.
Destination IP Address If you selected Specific IP Address in the previous item, enter the destination device’s IP
address here. Otherwise this field will be hidden if you select the detected device.
IP Type Select between IPv4 or IPv6. Compared to IPv4, IPv6 (Internet Protocol version 6), is
designed to enhance IP address size and features. The increase in IPv6 address size to
128 bits (from the 32-bit IPv4 address) allows up to 3.4 x 1038 IP addresses. The Zyxel
Device can use IPv4/IPv6 dual stack to connect to IPv4 and IPv6 networks, and supports
IPv6 rapid deployment (6RD).
Select Service Select a service from the Select Service box.
Protocol Select the protocol (ALL, TCP/UDP, TCP, UDP, ICMP, or ICMPv6) used to transport the
packets for which you want to apply the rule.
