Section 2 Getting Started Accessing Displays
3BUR002418-600 A 27
MOD 300 Objects and Associated Aspects
Table 1 shows the relationships between MOD 300 objects and aspects.
Table 1. MOD 300 Objects and Associated Aspects
MOD 300 Objects Associated Aspects
MOD_DB MOD 300 System Status,
Alarm and Event Lists (CCF Alarm, Diagnostic
Message, TCL Message)
MOD_AREA MOD 300 System Status
MOD_AC460 MOD300 AC460 PS Status,
MOD 300 System Status
MOD_AC460MOD MOD300 AC460 PS Status, MOD300 Message,
MOD300 System Performance,
MOD 300 System Status
MOD_AC410 MOD300 AC410 PS Status, MOD300 Message,
MOD300 System Performance,
MOD 300 System Status
MOD_CCF
MOD_CTRL_BLOCK
MOD 300 System Status
MOD_CCF_CONTIN_LOOP MOD300 Alarm Summary, MOD300 Loop Detail,
MOD300 Loop FCM, Faceplate, Alarm List,
Measure_DVAlue
MOD_CCF_CNTRL_LOOP MOD300 Alarm Summary, MOD300 Loop Detail,
MOD300 Loop FCM, Faceplate, Alarm List,
Measure_DVAlue
Output_DValue
MOD_CCF_PID_LOOP MOD300 Alarm Summary, MOD300 Loop Detail,
MOD300 Loop FCM, Faceplate, Alarm List,
Measure_DVAlue, Output_DValue,
Setpoint_DValue
