ABB Advant Controller 450 User Manual

$GYDQW

&RQWUROOHU8VHU¶V*XLGH
&KDSWHU &RQILJXUDWLRQ$SS OLFDWLRQ%XLOGLQJ
3-70 3BSE 002 415R701 Rev A
Signals used and pinning in the communication board CI531 for RS-232-C are shown in
Table 3-24.
 $YDLODELOLW\
The reliability and availability of an Advant Controller 450 and its I/O can be calculated on
request. Such a calculation can be adapted to the actual application and it can be extended to
include all Advant OCS equipment in an automation system.
7DEOH 3ULQWHU'DWDZKLFK0XVWEH)XOILOOHG
'DWD 9DOXH
Character code Standard 7 bits ASCII
Parity None
Number of stop bits 1
Data word length 8 bits
Type of interface RS-232-C
Baud rate 9600 bits/s
Protocol X
ON
/X
OFF
No. of characters per line 72
Printer speed 160 characters/s
Limit for X
off
/Busy Min. 226 bytes
7DEOH 3ULQWHU6LJQDOV56&
3LQ 6KRUW 'HVFULSWLRQ
1 DCD Data Carrier Detect
2 RD Receive Data
3 TD Transmit Data
4 DTR Data Terminal Ready
5 GND Ground
6 DSR Data Set Ready
7 RTS Request To send
8 CTS Clear To Send
9 (RI) (Ring Indicator)
