Section I.3 List of System Messages and Corrective Actions
3BSE 002 415R701 Rev A I-7
17 8 Hardware error 02 H’CCSSTT00
CC
SS
TT
CS513 error
Carrier position in the subrack
Submodule position on the carrier
Type of error:
- 03= Checksum error in received frame
- 04= CS513 missing/not accessible
- 0A= Late collision while transm. a frame
- 0B= Loss of carrier from transceiver
- 0D= Controller failed to transm. frame
- 44= Controller failed to initialize
- 48= Babble error. Frame > 1518 bytes
- 49= Transc. “heart beat error. Transc. is
not properly connected or the
SQE test is not working.
03 H’CC00EE00
CC
EE
SC520 error
Carrier position in the subrack
Type of error:
- 01= Failed to initialize
- 03= Board has halted
- 04= Board missing or not accessible
04 H’CCSSEE00
CC
SS
EE
CI532/535 error
Carrier position in subrack
Submodule position on the carrier
Type of error:
- 01= Failed to initialize
- 03= Board has halted
- 04= Board missing or not accessible
05 H’CCSSEE00
CC
SS
EE
CI531 error
Carrier position in subrack
Submodule position on the carrier
Type of error:
- 01= Failed to initialize
- 03= Board has halted
- 04= Board missing or not accessible
9 Hardware in
working order
02
03
04
05
H’CCSS0000
CC
SS
CS513 in working order
SC520 in working order
CI532/535 in working order
CI531 in working order
Carrier position in subrack
Submodule position on the carrier (if relevant]
Table I-6. Type 17, Code 1, 2, 3, 7, 8, 9 and 11 (Continued)
Type Code Significance Data 1 Data 2 Comments/Actions
