ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Appendix I System Messages
I-18 3BSE 002 415R701 Rev A
28 39 Concept,
instance No.
A previous hardware error has vanished. The board
or node is taken into operation again.
H’015D
(349),x
H’xxxxyyyy MasterFieldBus
xxxx = Bus number
yyyy = Not used.
H’00B5
(181),x
H’xxxxyyyy MasterFieldBus nodes
xxxx = Bus number
yyyy = Node number
H’014D
(333),x
H’xxxxyyzz AF100 and PROFIBUS
xxxx = Bus number
yy= 0 No redundant CI52x
yy= 1 CI52x sub module 1
yy= 2 CI52x sub module 2
zz = Station number (of CI52x or CI541)
H’014E
(334),x
H’xxxxyyyy AF100 stations and PROFIBUS slaves
xxxx = Bus number
yyyy = Station number
H’0145
(325),x
H’wwxxyyzz S800 I/O modules
ww = Bus number
xx = Station number
yy = Cluster number
zz = Position number
H’0167
(359),x
H’xxxxyyyy Single DSBC176 or redundant DSBC174 bus
extender.
xxxx = 400 Status word from DSBC17x
yyyy = 1 Left DSBC17x connected to left CPU.
yyyy = 2 Right DSBC174 connected to right CPU
55 Concept,
instance No.
Gain factor for linearization of Pt 100 outside
permissible value
56 Time interval or accumulated time for pulse counter
outside permitted value.
Table I-12. Type 28 (Continued)
Type Code Data 1 Data 2 Comments/Actions
