Section I.3 List of System Messages and Corrective Actions
3BSE 002 415R701 Rev A I-19
28 74 Concept,
instance No.
H’015F
(351),x
H’0000000x Reference in EVS(R), AIEV or DIEV, cannot be
found. Less number of references than in
corresponding EVS(S) or reference is of wrong
type.
Example: REF5 in EVS(S) is a DIC but REF5 in
EVS(R) is an AIEV.
x = 9 Reference is neither AIEV nor DIEV, probably
missing.
x = A Reference is AIEV instead of DIEV or vice
versa.
x = B Reference is not AIEV or DIEV or is not
active.
76 Concept,
instance No.
H’015F
(351),x
H’0000000x EVS(R) has been removed. Reconfiguration will be
done.
x = 0 Removed EVS(R) belonged to AF 100
x = 1..9 Removed EVS(R) belonged to RCOM
network ‘x‘.
-1 Concept,
instance No.
H’014D
(333),x
H’xxxxxxxx Process error diagnostics from remote device
AF100, 32-bit process error diagnostic.
xxxxxxxx = H’20000000, More than 50 errors
xxxxxxxx = H’40000000, Simultaneous bus masters
xxxxxxxx = H’80000000, Redundant line failed
-2 Concept,
instance No
H’014D
(333),x
H’xxxxyyzz AF100 device.error
xxxx = Bus number
yy = 0 No redundant CI52x
yy = 1CI52x sub module
yy = 2 CI52x sub module 2
zz = Station number (of CI52x)
Table I-12. Type 28 (Continued)
Type Code Data 1 Data 2 Comments/Actions
