Section I.3 List of System Messages and Corrective Actions
3BSE 002 415R701 Rev A I-21
28 -5 Concept,
instance No
Minor Device/Station Error or I/O S800 Module
warning. Nonfatal hardware error.
H’0145
(325),x
H’wwxxyyzz S800 I/O modules
ww = Bus number
xx = Station number
yy = Cluster number
zz = Position number
H’014E
(334),x
H’xxxxyyyy CI810 or CI820
xxxx = Bus number
yyyy = Station number
H’014D
(333),x
LONWORKS channel
The configured location, subnet or/and node for the
channel does not match the actual values in the
device.
-6 Concept,
instance No
Communication error
H’014D
(333),x
H’xxxxyyzz AF100 and PROFIBUS. Communication Error.
Reason: No contact with device
xxxx = Bus number
yy = 0 No redundant CI52x
yy = 1 CI52x sub module 1
yy = 2 CI52x sub module 2
zz = Station number (of CI52x or CI541V1)
-8 Concept,
instance No.
H’014D
(333),x
Bus controller CI52x halted
-9 Diagnostics info Fatal bus error in CI52x, modem or cable
-10 H’xxxxyyzz Redundant communication media error
xxxx = Bus number
yy = 0 Non-redundant
yy = 1 CI522 module I
yy = 2 CI522 module II
zz = Cable number
-11 H’xxxxyyzz Redundant communication media in working order
xxxx = Bus number
yy= 0 Non-redundant
yy = 1 CI522 module I
yy = 2 CI522 module II
zz = Cable number
-14 H’xxxxyyyy Redundant board changeover
xxxx= Internal information
yyyy= New primary CI522 module number
Table I-12. Type 28 (Continued)
Type Code Data 1 Data 2 Comments/Actions
