ABB Advant Controller 450 User Manual

Advant
®
Controller 450 User’s Guide
Appendix I System Messages
I-22 3BSE 002 415R701 Rev A
Table I-13. Type 29, Code 1, 2, 3 and 4
Type Code Significance Address Comments/Actions
29 1 Message from redundant
processor module
diagnostics
1
3
4
Changeover has been performed automatically.
Fault in backup processor module.
Diagnostics fault.
2 Memory error in processor
module RAM
1
2
The frequency of corrected bit-errors has exceeded a
certain limit. Data 1 = processor module position.
The total number of corrected bit errors has exceeded
a certain limit. Data 1 = processor module position.
Program card supervision H’10
H’11
H’12
H’13
Correct program card (PCMCIA 2.0) replaced.
Program card memory checksum error.
Program card removed (missing card).
Wrong program card.
For the addresses H’10..H’13 data 1 and data 2 give
the position and subposition respectively.
3 Incorrect backup voltage for
RAM
1 Check battery backup.
4 Message from minute pulse
handler
1
2
No minute pulse available (
≥
3 pulses missing)
Minute pulse outside time range. Data 1 gives the
difference in units of 0.1 ms.
18:33:55 29 2 CXKK600
Type 29 Redundant Processor Modules, Operating System, Kernel
1
511
1
H’00000012
