Section I.3 List of System Messages and Corrective Actions
3BSE 002 415R701 Rev A I-23
Table I-14. Type 30, Code 21, 23
Type Code Significance Address Data 1 Data 2 Comments/Actions
30 21 Overload in receiving end. H’EEAC
(=61100)
1
(channel
full)
H’XXYY0000 Routine:
CXAA000 DS (MV 300)
CXAM000 DS [MVI, RCOM)
CXAT000 TS (MV 300)
XX= Destination network
YY= Destination node
Overload in receiving end. Message
ident.
number
Dest.
netw.
Destination
node
Routine:
CXAF00x (EXCOM)
23 Fault in the data base
element (DS, MS, TS).
There are no data
references.
DS or MS has been
blocked.
H’EB28
(=60200)
4 DS, MS, TS
number
Routine:
CXAA000 DS (MV 300)
CXAM000 DS [MVI, RCOM)
CXAT000 TS (MV 300)
Incorrect polling time at
receiving data base
element (DS or MS).
DS or MS blocked.
H’ED1D
(=60701)
4DS, MS
number
Routine:
CXAA000 DS (MV 300)
CXAM000 DS [MVI, RCOM)
Transmitting and receiving
data base elements (DS,
MS, TS) have different data
references.
H’ED80
(=60800)
4 H’XXXXYYYY Routine:
CXAA000 DS (MV 300)
CXAM000 DS [MVI, RCOM)
CXAT000 TS (MV 300)
XXXX= Number of data
references in DS,
MS or TS
YYYY= DS, MS or TS
number
13:25:09 30 21 CXAA000
Type 30 MasterBus (Data Set, EXCOM)
H’1010002
H118100FF11
1
H’EEAC
