Section I.3 List of System Messages and Corrective Actions
3BSE 002 415R701 Rev A I-25
Table I-15. Type 39
Type Code Significance Data 1 Data 2 Comments/Actions
39 1 Configuration of DSPs on
the communication
interface or changing the
DSP state has failed.
Concept,
instance of
first DSP
concerned
Result from
board operation
Command time out or hardware
error
2 DSPs exist which are
scanned slower than
definition.
Basic cycle time
used in HEX
One or several DSPs are defined for
a CYCLETIM< basic cycle time. The
DSPs concerned are updated with
the basic cycle time. The basic cycle
time is changed with the APP
command.
5 Unconfigured DSPs exist No data 1. One or several unconfigured
DSPs have been found after
configuration at start-up. The
DSPs might automatically be
configured at reconfiguration.
2. Previous configuration failed.
6 Communication to the
communication interface
is lost.
See
Comments
See Comments The communication interface is
removed or does not function
properly.
For messages with address:
00230011, 00240011, 00240012
Data 1: DSP data base concept,
instance number
Data 2: No data
For messages with address:
00040012
Data 1: 0
Data 2: Logical bus number
13:25:10 39 6
Type 39 Data Set Peripheral, Advant Fieldbus 100
H’014F0001
11
1
H’00230011
CXAP000
